DOB 86mm AC LED Module 3000K 4000K 5000K 5700K 6500K

Product Categories
Shenzhen Relight Technology Co., Ltd./Shenzhen Relight Lighting Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

DOB 86mm AC LED Module 3000K 4000K 5000K 5700K 6500K

  • 1
  • 2
  • 3

Brand Name : RELIGHT

Model Number : DOB Module

Certification : CE,ETL,UL

Place of Origin : CHINA

MOQ : 100M

CRI : 90/80

Protection : IP20

Input : 200-240Vac

Frequency : 50/60Hz

Beam Angle : 120 deg

Power : AC

Various CCT available : 2700/3000/4000/5000/5700/6500K

Price : Contact us to get best price

Delivery Time : 2-3weeks

Payment Terms : T/T

Supply Ability : 10000M/M

Contact Now

  • Connects directly to AC Power
  • Various CCT available: 2700/3000/3500/4000/5000/5700/6500K
  • CRI: 90/80
  • Macadam 5 steps color bin
  • Solutions for Down light / Spotlight/Candle light/Ceiling light
  • AC line voltage 230V input directly
  • Power factor higher than 0.9
  • TRIAC dimmable

DOB 86mm AC LED Module 3000K 4000K 5000K 5700K 6500K

DOB 86mm AC LED Module 3000K 4000K 5000K 5700K 6500K

Absolute maximum rating at 25℃

P/N
Size
Input
Power
PF
Flux
Efficiency
CCT
CRI
Dimming
mm
Vac
W
-
Lm
Lm/W
K
-
-
RL-HMD86A2802H018-827FF
Ø86
230
18
0.9
1980
110
2700
80
TRIAC
RL-HMD86A2802H018-830FF
Ø86
230
18
0.9
2070
115
3000
80
TRIAC
RL-HMD86A2802H018-840FF
Ø86
230
18
0.9
2160
120
4000
80
TRIAC
RL-HMD86A2802H018-850FF
Ø86
230
18
0.9
2160
120
5000
80
TRIAC
RL-HMD86A2802H018-865FF
Ø86
230
18
0.9
2160
120
6500
80
TRIAC

Optical-Electrical Characteristics at 25℃

Input 200-240Vac
Frequency 50/60Hz
Rated power Typical power(±10% tolerance)
PF >0.90
Protection IP20
Surge level 2.5KV
Hi-pot 1.5KVac
Storage temperature -30-85℃
Operation temperature -30-80℃(Ts ofled components)
Beam Angle 120 deg
Flicker index <5%

DOB 86mm AC LED Module 3000K 4000K 5000K 5700K 6500K

DOB 86mm AC LED Module 3000K 4000K 5000K 5700K 6500K

DOB 86mm AC LED Module 3000K 4000K 5000K 5700K 6500K

Safety Information
1. The LED module and all its components shall not be subjected to mechanical stress.
2. Correct electrical polarity, or not module may be damaged.
3. Ensure the power supply is suitable for the total load.
4. Electrostatic Discharge (ESD) precautions shall be incorporated when handling or installing the module.
5. Installation of LED modules shall be made refering to all applicable electrical and safety standards.
6. Suitable for luminaire of protection class 1, grounding is mandatory to comply with safety standards.
7. The AC light engine needs to be mounted to a heat sink with a thermal interface material between them.
8. It is better to use the AC led module with safety cover.
9. Modules may be hot to the touch. Use caution when handling.
